Associated Spring Raymond - M10x1.5 Mt Hole, 3.94" Rod Diam, 5.91" Diam, 16mm Max Stroke, Nitrogen Gas Spring Cylinder - 5.35" OAL, 56,600 Lb Full Stroke Spring Force, 2,175 psi Initial Charge
Item #: 75003954
Brand: Associated Spring Raymond
Model #: CU 18300-016
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Diameter (Decimal Inch) | 5.9100 |
| Maximum Stroke (Decimal Inch) | 0.625 |
| Maximum Stroke (mm) | 16.00 |
| Spring Force Full Stroke | 56600 |
| Spring Force Initial | 41000.0 |
| Overall Length (Decimal Inch) | 5.3500 |
| Initial Charge Pressure | 2175 |
| Mounting Hole Thread Size | M10x1.5 |
| Rod Diameter (Decimal Inch) | 3.940 |
