Guardian Electric - 100 Milliamp, 1/8 to 1 Inch Stroke, Pull Force, D Frame Electrical Solenoid - 120 VAC Volt, Quick Connect, 1.84 Inch Long
Item #: 74097973
Brand: Guardian Electric
Model #: 11-C-120A
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Solenoid Type | D-Frame |
| Action | Pull |
| Maximum Stroke (Decimal Inch) | 1 |
| Minimum Stroke (Decimal Inch) | 1/8 |
| Maximum Pull Force (oz.) | 13 |
| Minimum Pull Force (oz.) | 4 |
| Amperage (mA) | 100 |
| Voltage | 120 VAC |
| Terminal Type | Quick Connect |
| Overall Length (Decimal Inch) | 1.8400 |
| Overall Width (Decimal Inch) | 1.1900 |
| Overall Height (Decimal Inch) | 1.1900 |
| Coil Resistance (Ohms) | 225 |
| Duty Cycle | Continuous |
| Standards Met | RoHS Compliant 2002/95/EC; UL Recognized |
