Guardian Electric - 1.01 Amp, 0.05, 1 Inch Stroke, Pull Force, C Frame Electrical Solenoid - 12 VDC Volt, Quick Connect, 1.13 Inch Long
Item #: 74097601
Brand: Guardian Electric
Model #: 28-I-12D
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Solenoid Type | C-Frame |
| Action | Pull |
| Maximum Stroke (Decimal Inch) | 1 |
| Minimum Stroke (Decimal Inch) | 0.0500 |
| Maximum Pull Force (oz.) | 32 |
| Minimum Pull Force (oz.) | 2 |
| Amperage | 1.01 |
| Voltage | 12 VDC |
| Terminal Type | Quick Connect |
| Overall Length (Decimal Inch) | 1.1300 |
| Overall Width (Decimal Inch) | 1.1900 |
| Overall Height (Decimal Inch) | 1.0800 |
| Coil Resistance (Ohms) | 11.90 |
| Duty Cycle | Intermittent |
| Standards Met | RoHS Compliant 2002/95/EC; UL Recognized |
