Milling Insert: APHW 100308SR TCM10, TCM10, Cermet N/A Finish,
Item #: 73550287
Brand: Ceratizit
Model #: 5114630803
Product Specifications
| Insert Style | APHW |
| Insert Size Code | 1003 |
| Insert Material | Cermet |
| Manufacturer Grade | TCM10 |
| Inscribed Circle (Decimal Inch) | 0.2618 |
| Corner Radius (Decimal Inch) | 0.0315 |
| Insert Hand | Right Hand |
| Relief Angle | 11.00 |
| Series | APHW |
| Coating Process | Uncoated |
| Hole Diameter (Decimal Inch) | 0.1102 |
| Maximum Depth of Cut (Decimal Inch) | 0.2667 |
| Number Of Cutting Edges | 2 |
| Cutting Edge Effective Length (Decimal Inch) | 0.3976 |
| Insert Shape | Parallelogram |
| Rake | Positive |
| Primary Workpiece Material | Steel |
| Primary Workpiece Material Code | P |
| Secondary Workpiece Material | Cast Iron |
| Secondary Workpiece Material Code | K |
| Iso Code | APHW 100308SR TCM10 |
| Chip Breaker | SR |
| Coating/Finish | Uncoated |
| Included Angle Degree | 85 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1378 |
