Associated Spring Raymond - 27.5mm OD, 2.5mm Wire, 115mm Free Length, Compression Spring - 17.1 Lb Spring Rating, 233.4 N Max Work Load, Music Wire
Item #: 73348328
Brand: Associated Spring Raymond
Model #: D13110
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 27.51 |
| Outside Diameter (Decimal Inch) | 1.0830 |
| Free Length (mm) | 115.01 |
| Free Length (Decimal Inch) | 4.5280 |
| Spring Rate Pounds per Inch (Pounds) | 17.1000 |
| Maximum Work Load (N) | 233.39999390 |
| Solid Height (mm) | 26.24 |
| Solid Height (Decimal Inch) | 1.0330 |
| Material | Music Wire |
| Wire Size (mm) | 2.49 |
| Wire Size (Decimal Inch) | 0.0980 |
