Associated Spring Raymond - 24.77mm OD, 1.88mm Wire, 2-1/2" Free Length, Compression Spring - 10.2 Lb Spring Rating, 54.04 N Max Work Load, Music Wire
Item #: 72596695
Brand: Associated Spring Raymond
Model #: C09750742500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24.77 |
| Outside Diameter (Decimal Inch) | 0.9750 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 10.2000 |
| Maximum Work Load (N) | 54.04000092 |
| Solid Height (mm) | 15.57 |
| Solid Height (Decimal Inch) | 0.6130 |
| Material | Music Wire |
| Wire Size (mm) | 1.88 |
| Wire Size (Decimal Inch) | 0.0740 |
