Associated Spring Raymond - 9.14mm OD, 1.4mm Wire, 3/4" Free Length, Compression Spring - 90.6 Lb Spring Rating, 89.58 N Max Work Load, Music Wire
Item #: 71496913
Brand: Associated Spring Raymond
Model #: C03600550750M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 19.05 |
| Free Length (Decimal Inch) | 3/4 |
| Spring Rate Pounds per Inch (Pounds) | 90.6000 |
| Maximum Work Load (N) | 89.58000183 |
| Solid Height (mm) | 11.35 |
| Solid Height (Decimal Inch) | 0.4470 |
| Material | Music Wire |
| Wire Size (mm) | 1.40 |
| Wire Size (Decimal Inch) | 0.0550 |
