Value Collection - 3/4-10 UNC Grade 2 Hex Lock Nut with Expanding Flex Top - 1-1/16" Width Across Flats, 57/64" High, Cadmium-Plated Finish
Item #: 70998000
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Hex lock nuts are the most common type of lock nut. They have six uniform sides that create a flat bearing surface.
| Product Specifications | |
|---|---|
| System of Measurement | Inch |
| Type | Hex Lock Nut |
| Material | Steel |
| Thread Size | 3/4-10 |
| Height (Inch) | 57/64 |
| Height (Decimal Inch) | 0.8840 |
| Material Grade | Grade 2 |
| Finish/Coating | Cadmium-Plated |
| Thread Direction | Right Hand |
| Locking Style | Expanding Flex Top |
| Flange Diameter (Decimal Inch) | 1.0520 |
| Width Across Flats (Inch) | 1-1/16 |
| Width Across Flats (Decimal Inch) | 1.0520 |
| Thread Standard | UNC |
| Fastener Standard | IFI 100/107; NASM 25027 |
| Military Specification | Does Not Meet Military Specifications |
