Replaceable Drill Tips: TMA1270R01 IN2505, 0.5000" Dia, 140 deg Point, IN2505
Item #: 45001922
Brand: Ingersoll Cutting Tools
Model #: 5120128
Product Specifications
| Cutting Diameter (Inch) | 1/2 |
| Cutting Diameter (Decimal Inch) | 0.5000 in |
| Tip Material | Solid Carbide |
| Manufacturer Grade | IN2505 |
| Material Grade | M15; M35 |
| Series | TMA |
| Coating Process | PVD |
| Insert Seat Size | 12.5 |
| Functional Length (Decimal Inch) | 0.1990 |
| Primary Workpiece Material | Stainless Steel |
| Primary Workpiece Material Code | M |
| Standards | ANSI |
| Height (mm) | 7.00 |
| Overall Length/Projection (Decimal Inch) | 0.2760 |
| Drill Point Angle | 140 |
| Flute Type | Helical |
| Insert Holding Method | Clamp |
| ISO Number | TMA1270R01 IN2505 |
| Coolant Through | Yes |
| Flute Length (mm) | 5.00 |
| Point Type | Standard |
| Spiral Type | Regular Spiral |
| Style | TMA |
| UNSPSC Code | 23242105 |
| Applications | Drilling; Coolant-Thru; Spot Drilling |
| Coating/Finish | TiN; TiAlN |
| Included Angle Degree | 140 |
| Number Of Flutes | 2 |
