Value Collection - 3/8-16, 0.53 Insert Diam, 0.69" OAL, Sealed Head Open End Threaded Insert - 0.5312" Hole Diam, 0.685" Head Diam, 1008/1010 Steel, Clear Protective Coating & Zinc Yellow Dichromate Finish
Item #: 70927926
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Sealed head open end inserts have a weathertight seal under the head and are open on both ends.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Type | Sealed Head Open End |
| System of Measurement | Inch |
| Thread Size | 3/8-16 |
| Overall Length (Decimal Inch) | 0.6900 |
| Insert Diameter (Decimal Inch) | 0.5300 |
| Hole Diameter (Decimal Inch) | 0.5312 |
| Material | Steel |
| Head Diameter (Decimal Inch) | 0.6850 |
| Material Grade | 1008/1010 |
| Finish/Coating | Clear Protective Coating; Zinc Yellow Dichromate |
| Minimum Grip (Decimal Inch) | 0.0270 |
| Maximum Grip (Decimal Inch) | 0.1150 |
| Head Height (Decimal Inch) | 0.0350 |
| Drill Size (Inch) | 17/32 |
| Thread Standard | UNC |
