Corner Radius End Mill: 1" Dia, 3" LOC, 0.0600" Radius, 5 Flute, Solid Carbide
Item #: 13486634
Brand: Accupro
Model #: 14777951
Product Specifications
| Mill Diameter (Inch) | 1 |
| Mill Diameter (Decimal Inch) | 1.0000 |
| Number Of Flutes | 5 |
| Length of Cut (Inch) | 3 |
| Single Or Double End | Single |
| End Mill Material | Solid Carbide |
| Coating/Finish | Bright/Uncoated |
| Overall Length (Inch) | 5-1/2 |
| Centercutting | No |
| Flute Direction | Right Hand |
| Corner Radius (Decimal Inch) | 0.0600 |
| Variable Index | Yes |
| Variable Helix | No |
| Cutting Direction | Right Hand |
| Coolant Through | Yes |
| Overall Length (Decimal Inch) | 5.5000 |
| Chipbreaker | Yes |
| Length Of Cut (Decimal Inch - 4 Decimals) | 3.0000 |
| Length Type | Standard |
| Flute Type | Spiral |
| Extended Reach | No |
| Shank Type | Straight-Cylindrical |
| Mill Diameter Tolerance | +0.000000/-0.002000 in |
| Shank Diameter Tolerance | -0.0001/-0.0004 in |
| UNSPSC Code | 27112803 |
| Material Grade | Micrograin |
| Series | AL-5 |
| Material Application | Aluminum |
