Schneider Electric - 7 Watt, 0.30 Amp, 100 to 240 VAC, 120 to 250 VDC Input, 24 VDC Output, DIN Rail, Panel Power Supply - Screw Connection, 60mm Wide x 59mm Deep x 100mm High, 78-100% Efficiency, Green LED Output
Item #: 69523678
Brand: Schneider Electric
Model #: ABL8MEM24003
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Mounting Type | DIN Rail; Panel |
| Output Wattage | 7 |
| Maximum Input Voltage | 100-240 VAC; 120-250 VDC |
| Minimum Input Voltage | 100 VAC; 120 VDC |
| Output Voltage | 24 VDC |
| Output Amperage | 0.30 |
| Number of Phases | 1 or 2 |
| Connection Type | Screw |
| Hold-up Time (ms) | 10 @ 100 V; 150 @ 230 V |
| Efficiency | 78-100 % |
| Ingress Protection Rating | IP20 |
| Status Indicator | Green LED (Output) |
| Overall Height (mm) | 100 |
| Overall Width (mm) | 60 |
| Overall Depth (mm) | 59 |
| Standards Met | cCSAus; CSA 22-2 No. 950-1; C-Tick; cULus 508; TUV 60950-1 |
