Associated Spring Raymond - M8 Int Rod, G1/8 Fill Port, M8 Mt Hole, 25mm Rod Diam, 50.2mm Diam, 100mm Max Stroke, Black Nitrogen Gas Spring Cylinder - 195mm Body Length, 295mm OAL, 2,700 Lb Full Stroke Spring Force, 360 psi Initial Charge
Item #: 69158657
Brand: Associated Spring Raymond
Model #: TU 750-100
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Mounting Hole Thread Size | M8 |
| Internal Rod Thread (mm) | M8 |
| Fill Port | G1/8 |
| Color | Black |
| Initial Charge Pressure (psi) | 360 |
| Initial Charge Pressure (bar) | 25 |
| Diameter (mm) | 50.20 |
| Body Length (mm) | 195 |
| Body Length (Decimal Inch) | 7.6772 |
| Diameter (Decimal Inch) | 1.9764 |
| Spring Force Initial (N) | 7406 |
| Spring Force Initial (lbf) | 1665 |
| Spring Force Full Stroke (N) | 12010 |
| Spring Force Full Stroke (lbf) | 2700 |
| Rod Diameter (mm) | 25 |
| Rod Diameter (Decimal Inch) | 0.9843 |
| Overall Length (mm) | 295 |
| Overall Length (Decimal Inch) | 11.6142 |
| Maximum Stroke (mm) | 100 |
| Maximum Stroke (Decimal Inch) | 3.9370 |
