Associated Spring Raymond - M16 Int Rod, G1/8 Fill Port, M12 Mt Hole, 95mm Rod Diam, 194.9mm Diam, 250mm Max Stroke, Black Nitrogen Gas Spring Cylinder - 410mm Body Length, 660mm OAL, 35,970 Lb Full Stroke Spring Force, 360 psi Initial Charge
Item #: 69158202
Brand: Associated Spring Raymond
Model #: TU 10000-250
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Mounting Hole Thread Size | M12 |
| Internal Rod Thread (mm) | M16 |
| Fill Port | G1/8 |
| Color | Black |
| Initial Charge Pressure (psi) | 360 |
| Initial Charge Pressure (bar) | 25 |
| Diameter (mm) | 194.90 |
| Body Length (mm) | 410 |
| Body Length (Decimal Inch) | 16.1417 |
| Diameter (Decimal Inch) | 7.6732 |
| Spring Force Initial (N) | 106001 |
| Spring Force Initial (lbf) | 23830 |
| Spring Force Full Stroke (N) | 160003 |
| Spring Force Full Stroke (lbf) | 35970 |
| Rod Diameter (mm) | 95 |
| Rod Diameter (Decimal Inch) | 3.7402 |
| Overall Length (mm) | 660 |
| Overall Length (Decimal Inch) | 25.9843 |
| Maximum Stroke (mm) | 250 |
| Maximum Stroke (Decimal Inch) | 9.8425 |
