Associated Spring Raymond - 14mm OD, 2.8mm Wire, 71.4mm Free Length, Compression Spring - 136.65 Lb Spring Rating, 432.61 N Max Work Load, Stainless Steel
Item #: 69092567
Brand: Associated Spring Raymond
Model #: D23220
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 14 |
| Outside Diameter (Decimal Inch) | 0.5510 |
| Free Length (mm) | 71.40 |
| Free Length (Decimal Inch) | 2.8110 |
| Spring Rate Pounds per Inch (Pounds) | 136.6500 |
| Maximum Work Load (N) | 432.60998535 |
| Solid Height (mm) | 49 |
| Solid Height (Decimal Inch) | 1.9290 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.79 |
| Wire Size (Decimal Inch) | 0.1100 |
