Associated Spring Raymond - 24mm OD, 2.21mm Wire, 39.2mm Free Length, Compression Spring - 31.25 Lb Spring Rating, 138.15 N Max Work Load, Stainless Steel
Item #: 69092369
Brand: Associated Spring Raymond
Model #: D22920
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24 |
| Outside Diameter (Decimal Inch) | 0.9450 |
| Free Length (mm) | 39.19 |
| Free Length (Decimal Inch) | 1.5430 |
| Spring Rate Pounds per Inch (Pounds) | 31.2500 |
| Maximum Work Load (N) | 138.14999390 |
| Solid Height (mm) | 12.09 |
| Solid Height (Decimal Inch) | 0.4760 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.21 |
| Wire Size (Decimal Inch) | 0.0870 |
