Associated Spring Raymond - 11.6mm OD, 2mm Wire, 26.5mm Free Length, Compression Spring - 141.31 Lb Spring Rating, 264.88 N Max Work Load, Stainless Steel
Item #: 69092195
Brand: Associated Spring Raymond
Model #: D22610
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 11.61 |
| Outside Diameter (Decimal Inch) | 0.4570 |
| Free Length (mm) | 26.49 |
| Free Length (Decimal Inch) | 1.0430 |
| Spring Rate Pounds per Inch (Pounds) | 141.3100 |
| Maximum Work Load (N) | 264.88000488 |
| Solid Height (mm) | 15.01 |
| Solid Height (Decimal Inch) | 0.5910 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.01 |
| Wire Size (Decimal Inch) | 0.0790 |
