Associated Spring Raymond - 9.6mm OD, 1.6mm Wire, 45mm Free Length, Compression Spring - 49.47 Lb Spring Rating, 176.59 N Max Work Load, Stainless Steel
Item #: 69092096
Brand: Associated Spring Raymond
Model #: D22380
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.60 |
| Outside Diameter (Decimal Inch) | 0.3780 |
| Free Length (mm) | 45.01 |
| Free Length (Decimal Inch) | 1.7720 |
| Spring Rate Pounds per Inch (Pounds) | 49.4700 |
| Maximum Work Load (N) | 176.58999634 |
| Solid Height (mm) | 23.19 |
| Solid Height (Decimal Inch) | 0.9130 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
