Associated Spring Raymond - 13.74mm OD, 1.24mm Wire, 1-1/16" Free Length, Compression Spring - 17.27 Lb Spring Rating, 57.56 N Max Work Load, Stainless Steel
Item #: 69091981
Brand: Associated Spring Raymond
Model #: D22250
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 13.74 |
| Outside Diameter (Decimal Inch) | 0.5410 |
| Free Length (mm) | 27 |
| Free Length (Decimal Inch) | 1.0630 |
| Spring Rate Pounds per Inch (Pounds) | 17.2700 |
| Maximum Work Load (N) | 57.56000137 |
| Solid Height (mm) | 6.88 |
| Solid Height (Decimal Inch) | 0.2710 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.24 |
| Wire Size (Decimal Inch) | 0.0490 |
