Associated Spring Raymond - 9.25mm OD, 1.24mm Wire, 33mm Free Length, Compression Spring - 27.73 Lb Spring Rating, 87.49 N Max Work Load, Stainless Steel
Item #: 69091932
Brand: Associated Spring Raymond
Model #: D22170
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9-1/4 |
| Outside Diameter (Decimal Inch) | 0.3640 |
| Free Length (mm) | 32.99 |
| Free Length (Decimal Inch) | 1.2990 |
| Spring Rate Pounds per Inch (Pounds) | 27.7300 |
| Maximum Work Load (N) | 87.48999786 |
| Solid Height (mm) | 13.13 |
| Solid Height (Decimal Inch) | 0.5170 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.24 |
| Wire Size (Decimal Inch) | 0.0490 |
