Associated Spring Raymond - 8.79mm OD, 0.8mm Wire, 14.5mm Free Length, Compression Spring - 11.03 Lb Spring Rating, 16.28 N Max Work Load, Stainless Steel
Item #: 69091668
Brand: Associated Spring Raymond
Model #: D21750
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 8.79 |
| Outside Diameter (Decimal Inch) | 0.3460 |
| Free Length (mm) | 14-1/2 |
| Free Length (Decimal Inch) | 0.5710 |
| Spring Rate Pounds per Inch (Pounds) | 11.0300 |
| Maximum Work Load (N) | 16.28000069 |
| Solid Height (mm) | 5.21 |
| Solid Height (Decimal Inch) | 0.2050 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.79 |
| Wire Size (Decimal Inch) | 0.0310 |
