Associated Spring Raymond - 1.85mm OD, 0.25mm Wire, 6.2mm Free Length, Compression Spring - 5.71 Lb Spring Rating, 2.8 N Max Work Load, Stainless Steel
Item #: 69091023
Brand: Associated Spring Raymond
Model #: D20420
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 1.85 |
| Outside Diameter (Decimal Inch) | 0.0730 |
| Free Length (mm) | 6.20 |
| Free Length (Decimal Inch) | 0.2440 |
| Spring Rate Pounds per Inch (Pounds) | 5.7100 |
| Maximum Work Load (N) | 2.79999995 |
| Solid Height (mm) | 2.87 |
| Solid Height (Decimal Inch) | 0.1130 |
| Material | Stainless Steel |
| Wire Size (mm) | 1/4 |
| Wire Size (Decimal Inch) | 0.0100 |
