Associated Spring Raymond - 1.2mm OD, 0.2mm Wire, 3.9mm Free Length, Compression Spring - 9.66 Lb Spring Rating, 2.14 N Max Work Load, Stainless Steel
Item #: 69090595
Brand: Associated Spring Raymond
Model #: D20120
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 1.19 |
| Outside Diameter (Decimal Inch) | 0.0470 |
| Free Length (mm) | 3.91 |
| Free Length (Decimal Inch) | 0.1540 |
| Spring Rate Pounds per Inch (Pounds) | 9.6600 |
| Maximum Work Load (N) | 2.14000010 |
| Solid Height (mm) | 2.31 |
| Solid Height (Decimal Inch) | 0.0910 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.20 |
| Wire Size (Decimal Inch) | 0.0080 |
