Associated Spring Raymond - 24mm OD, 4mm Wire, 33.5mm Free Length, Compression Spring - 531.4 Lb Spring Rating, 1068.92 N Max Work Load, Music Wire
Item #: 69089548
Brand: Associated Spring Raymond
Model #: D13530
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24 |
| Outside Diameter (Decimal Inch) | 0.9450 |
| Free Length (mm) | 33-1/2 |
| Free Length (Decimal Inch) | 1.3190 |
| Spring Rate Pounds per Inch (Pounds) | 531.4000 |
| Maximum Work Load (N) | 1068.92004395 |
| Solid Height (mm) | 22 |
| Solid Height (Decimal Inch) | 0.8660 |
| Material | Music Wire |
| Wire Size (mm) | 3.99 |
| Wire Size (Decimal Inch) | 0.1570 |
