Associated Spring Raymond - 15mm OD, 2.5mm Wire, 47.5mm Free Length, Compression Spring - 137.2 Lb Spring Rating, 467.78 N Max Work Load, Music Wire
Item #: 69089233
Brand: Associated Spring Raymond
Model #: D12960
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.01 |
| Outside Diameter (Decimal Inch) | 0.5910 |
| Free Length (mm) | 47-1/2 |
| Free Length (Decimal Inch) | 1.8700 |
| Spring Rate Pounds per Inch (Pounds) | 137.2000 |
| Maximum Work Load (N) | 467.77999878 |
| Solid Height (mm) | 26.24 |
| Solid Height (Decimal Inch) | 1.0330 |
| Material | Music Wire |
| Wire Size (mm) | 2.49 |
| Wire Size (Decimal Inch) | 0.0980 |
