Associated Spring Raymond - 17.6mm OD, 1.6mm Wire, 77.5mm Free Length, Compression Spring - 11 Lb Spring Rating, 105.91 N Max Work Load, Music Wire
Item #: 69088961
Brand: Associated Spring Raymond
Model #: D12520
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 17.60 |
| Outside Diameter (Decimal Inch) | 0.6930 |
| Free Length (mm) | 77-1/2 |
| Free Length (Decimal Inch) | 3.0510 |
| Spring Rate Pounds per Inch (Pounds) | 11.0000 |
| Maximum Work Load (N) | 105.91000366 |
| Solid Height (mm) | 16.79 |
| Solid Height (Decimal Inch) | 0.6610 |
| Material | Music Wire |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
