Associated Spring Raymond - 11.6mm OD, 1.6mm Wire, 85mm Free Length, Compression Spring - 20.6 Lb Spring Rating, 169.66 N Max Work Load, Music Wire - Americas Industrial Supply

Associated Spring Raymond - 11.6mm OD, 1.6mm Wire, 85mm Free Length, Compression Spring - 20.6 Lb Spring Rating, 169.66 N Max Work Load, Music Wire


Item #: 69088912
Brand: Associated Spring Raymond
Model #: D12440
Exact Tooling IR#: 04

Product Specifications
Type Compression
Outside Diameter (mm) 11.61
Outside Diameter (Decimal Inch) 0.4570
Free Length (mm) 84.99
Free Length (Decimal Inch) 3.3460
Spring Rate Pounds per Inch (Pounds) 20.6000
Maximum Work Load (N) 169.66000366
Solid Height (mm) 32.79
Solid Height (Decimal Inch) 1.2910
Material Music Wire
Wire Size (mm) 1.60
Wire Size (Decimal Inch) 0.0630
$2.20
