Associated Spring Raymond - 7.3mm OD, 1mm Wire, 14.5mm Free Length, Compression Spring - 42.2 Lb Spring Rating, 34.13 N Max Work Load, Music Wire
Item #: 69088698
Brand: Associated Spring Raymond
Model #: D11910
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.29 |
| Outside Diameter (Decimal Inch) | 0.2870 |
| Free Length (mm) | 14-1/2 |
| Free Length (Decimal Inch) | 0.5710 |
| Spring Rate Pounds per Inch (Pounds) | 42.2000 |
| Maximum Work Load (N) | 34.13000107 |
| Solid Height (mm) | 7.49 |
| Solid Height (Decimal Inch) | 0.2950 |
| Material | Music Wire |
| Wire Size (mm) | 0.99 |
| Wire Size (Decimal Inch) | 0.0390 |
