Associated Spring Raymond - 8.64mm OD, 0.64mm Wire, 16mm Free Length, Compression Spring - 5.1 Lb Spring Rating, 10 N Max Work Load, Music Wire
Item #: 69088532
Brand: Associated Spring Raymond
Model #: D11550
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 8.64 |
| Outside Diameter (Decimal Inch) | 0.3400 |
| Free Length (mm) | 16 |
| Free Length (Decimal Inch) | 0.6300 |
| Spring Rate Pounds per Inch (Pounds) | 5.1000 |
| Maximum Work Load (N) | 10 |
| Solid Height (mm) | 4.09 |
| Solid Height (Decimal Inch) | 0.1610 |
| Material | Music Wire |
| Wire Size (mm) | 0.64 |
| Wire Size (Decimal Inch) | 0.0250 |
