Associated Spring Raymond - 3.84mm OD, 0.64mm Wire, 5.5mm Free Length, Compression Spring - 80.1 Lb Spring Rating, 20.99 N Max Work Load, Music Wire
Item #: 69088458
Brand: Associated Spring Raymond
Model #: D11350
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.84 |
| Outside Diameter (Decimal Inch) | 0.1510 |
| Free Length (mm) | 5.51 |
| Free Length (Decimal Inch) | 0.2170 |
| Spring Rate Pounds per Inch (Pounds) | 80.1000 |
| Maximum Work Load (N) | 20.98999977 |
| Solid Height (mm) | 4.09 |
| Solid Height (Decimal Inch) | 0.1610 |
| Material | Music Wire |
| Wire Size (mm) | 0.64 |
| Wire Size (Decimal Inch) | 0.0250 |
