Associated Spring Raymond - 5.5mm OD, 0.51mm Wire, 30mm Free Length, Compression Spring - 2.3 Lb Spring Rating, 8.04 N Max Work Load, Music Wire
Item #: 69088409
Brand: Associated Spring Raymond
Model #: D11280
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 5.51 |
| Outside Diameter (Decimal Inch) | 0.2170 |
| Free Length (mm) | 30 |
| Free Length (Decimal Inch) | 1.1810 |
| Spring Rate Pounds per Inch (Pounds) | 2.3000 |
| Maximum Work Load (N) | 8.03999996 |
| Solid Height (mm) | 7-3/4 |
| Solid Height (Decimal Inch) | 0.3050 |
| Material | Music Wire |
| Wire Size (mm) | 0.51 |
| Wire Size (Decimal Inch) | 0.0200 |
