Associated Spring Raymond - 25.4mm OD, 2.54mm Wire, 2-1/2" Free Length, Compression Spring - 209 Lb Spring Rating, 580.91 N Max Work Load, Chrome Alloy Steel
Item #: 69086544
Brand: Associated Spring Raymond
Model #: CV10002500100
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 25.40 |
| Outside Diameter (Decimal Inch) | 1 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 209.0000 |
| Maximum Work Load (N) | 580.90997314 |
| Solid Height (mm) | 31-3/4 |
| Solid Height (Decimal Inch) | 1-1/4 |
| Material | Chrome Alloy Steel |
| Wire Size (mm) | 2.54 |
| Wire Size (Decimal Inch) | 0.1000 |
