Associated Spring Raymond - 15.88mm OD, 2.057mm Wire, 76.2mm Free Length, Compression Spring - 100 Lb Spring Rating, 333.6 N Max Work Load, Chrome Alloy Steel
Item #: 69086023
Brand: Associated Spring Raymond
Model #: CV06253000081
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.88 |
| Outside Diameter (Decimal Inch) | 5/8 |
| Free Length (mm) | 76.20 |
| Free Length (Decimal Inch) | 3 |
| Spring Rate Pounds per Inch (Pounds) | 100.0000 |
| Maximum Work Load (N) | 333.60000610 |
| Solid Height (mm) | 48.01 |
| Solid Height (Decimal Inch) | 1.8900 |
| Material | Chrome Alloy Steel |
| Wire Size (mm) | 2.06 |
| Wire Size (Decimal Inch) | 0.0810 |
