Associated Spring Raymond - 15.88mm OD, 1.753mm Wire, 1-3/4" Free Length, Compression Spring - 96 Lb Spring Rating, 186.82 N Max Work Load, Chrome Alloy Steel
Item #: 69085934
Brand: Associated Spring Raymond
Model #: CV06251750069
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.88 |
| Outside Diameter (Decimal Inch) | 5/8 |
| Free Length (mm) | 44.45 |
| Free Length (Decimal Inch) | 1-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 96.0000 |
| Maximum Work Load (N) | 186.82000732 |
| Solid Height (mm) | 22.35 |
| Solid Height (Decimal Inch) | 0.8800 |
| Material | Chrome Alloy Steel |
| Wire Size (mm) | 1.75 |
| Wire Size (Decimal Inch) | 0.0690 |
