Associated Spring Raymond - 15.88mm OD, 2.84mm Wire, 1-1/4" Free Length, Compression Spring - 438 Lb Spring Rating, 366.07 N Max Work Load, Chrome Alloy Steel
Item #: 69085900
Brand: Associated Spring Raymond
Model #: CV06251250110
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.88 |
| Outside Diameter (Decimal Inch) | 5/8 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 438.0000 |
| Maximum Work Load (N) | 366.07000732 |
| Solid Height (mm) | 23.88 |
| Solid Height (Decimal Inch) | 0.9400 |
| Material | Chrome Alloy Steel |
| Wire Size (mm) | 2.79 |
| Wire Size (Decimal Inch) | 0.1100 |
