Associated Spring Raymond - 17.6mm OD, 1.6mm Wire, 110mm Free Length, Compression Spring - 6.18 Lb Spring Rating, 88.29 N Max Work Load, Stainless Steel
Item #: 69085777
Brand: Associated Spring Raymond
Model #: D22530
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 17.60 |
| Outside Diameter (Decimal Inch) | 0.6930 |
| Free Length (mm) | 110.01 |
| Free Length (Decimal Inch) | 4.3310 |
| Spring Rate Pounds per Inch (Pounds) | 6.1800 |
| Maximum Work Load (N) | 88.29000092 |
| Solid Height (mm) | 23.19 |
| Solid Height (Decimal Inch) | 0.9130 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
