Associated Spring Raymond - 14mm OD, 2.8mm Wire, 45.9mm Free Length, Compression Spring - 222.98 Lb Spring Rating, 432.61 N Max Work Load, Stainless Steel
Item #: 69085512
Brand: Associated Spring Raymond
Model #: D23210
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 14 |
| Outside Diameter (Decimal Inch) | 0.5510 |
| Free Length (mm) | 45.90 |
| Free Length (Decimal Inch) | 1.8070 |
| Spring Rate Pounds per Inch (Pounds) | 222.9800 |
| Maximum Work Load (N) | 432.60998535 |
| Solid Height (mm) | 32.21 |
| Solid Height (Decimal Inch) | 1.2680 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.79 |
| Wire Size (Decimal Inch) | 0.1100 |
