Associated Spring Raymond - 12.7mm OD, 1.321mm Wire, 4-1/2" Free Length, Compression Spring - 23 Lb Spring Rating, 115.2 N Max Work Load, Chrome Alloy Steel
Item #: 69085256
Brand: Associated Spring Raymond
Model #: CV05004500052
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.70 |
| Outside Diameter (Decimal Inch) | 1/2 |
| Free Length (mm) | 114.30 |
| Free Length (Decimal Inch) | 4-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 23.0000 |
| Maximum Work Load (N) | 115.19999695 |
| Solid Height (mm) | 57.15 |
| Solid Height (Decimal Inch) | 2-1/4 |
| Material | Chrome Alloy Steel |
| Wire Size (mm) | 1.32 |
| Wire Size (Decimal Inch) | 0.0520 |
