Associated Spring Raymond - 2.82mm OD, 0.33mm Wire, 6.8mm Free Length, Compression Spring - 7.5 Lb Spring Rating, 4.69 N Max Work Load, Music Wire
Item #: 69083848
Brand: Associated Spring Raymond
Model #: D10710
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 2.82 |
| Outside Diameter (Decimal Inch) | 0.1110 |
| Free Length (mm) | 6.81 |
| Free Length (Decimal Inch) | 0.2680 |
| Spring Rate Pounds per Inch (Pounds) | 7.5000 |
| Maximum Work Load (N) | 4.69000006 |
| Solid Height (mm) | 2.72 |
| Solid Height (Decimal Inch) | 0.1070 |
| Material | Music Wire |
| Wire Size (mm) | 0.33 |
| Wire Size (Decimal Inch) | 0.0130 |
