Associated Spring Raymond - 7.1mm OD, 0.8mm Wire, 10.5mm Free Length, Compression Spring - 27.2 Lb Spring Rating, 24.03 N Max Work Load, Music Wire
Item #: 69083558
Brand: Associated Spring Raymond
Model #: D11700
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.11 |
| Outside Diameter (Decimal Inch) | 0.2800 |
| Free Length (mm) | 10.49 |
| Free Length (Decimal Inch) | 0.4130 |
| Spring Rate Pounds per Inch (Pounds) | 27.2000 |
| Maximum Work Load (N) | 24.03000069 |
| Solid Height (mm) | 5.21 |
| Solid Height (Decimal Inch) | 0.2050 |
| Material | Music Wire |
| Wire Size (mm) | 0.79 |
| Wire Size (Decimal Inch) | 0.0310 |
