Associated Spring Raymond - 14.1mm OD, 1.6mm Wire, 78mm Free Length, Compression Spring - 15.6 Lb Spring Rating, 135.33 N Max Work Load, Music Wire
Item #: 69083350
Brand: Associated Spring Raymond
Model #: D12480
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 14.10 |
| Outside Diameter (Decimal Inch) | 0.5550 |
| Free Length (mm) | 78 |
| Free Length (Decimal Inch) | 3.0710 |
| Spring Rate Pounds per Inch (Pounds) | 15.6000 |
| Maximum Work Load (N) | 135.33000183 |
| Solid Height (mm) | 23.19 |
| Solid Height (Decimal Inch) | 0.9130 |
| Material | Music Wire |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
