Associated Spring Raymond - 11.6mm OD, 2mm Wire, 38.5mm Free Length, Compression Spring - 109.7 Lb Spring Rating, 317.74 N Max Work Load, Music Wire
Item #: 69083301
Brand: Associated Spring Raymond
Model #: D12620
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 11.61 |
| Outside Diameter (Decimal Inch) | 0.4570 |
| Free Length (mm) | 38.51 |
| Free Length (Decimal Inch) | 1.5160 |
| Spring Rate Pounds per Inch (Pounds) | 109.7000 |
| Maximum Work Load (N) | 317.73999023 |
| Solid Height (mm) | 21.01 |
| Solid Height (Decimal Inch) | 0.8270 |
| Material | Music Wire |
| Wire Size (mm) | 2.01 |
| Wire Size (Decimal Inch) | 0.0790 |
