Associated Spring Raymond - 18.5mm OD, 2.5mm Wire, 41mm Free Length, Compression Spring - 100.8 Lb Spring Rating, 364.81 N Max Work Load, Music Wire
Item #: 69083251
Brand: Associated Spring Raymond
Model #: D13000
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 18.49 |
| Outside Diameter (Decimal Inch) | 0.7280 |
| Free Length (mm) | 41 |
| Free Length (Decimal Inch) | 1.6140 |
| Spring Rate Pounds per Inch (Pounds) | 100.8000 |
| Maximum Work Load (N) | 364.80999756 |
| Solid Height (mm) | 18-3/4 |
| Solid Height (Decimal Inch) | 0.7380 |
| Material | Music Wire |
| Wire Size (mm) | 2.49 |
| Wire Size (Decimal Inch) | 0.0980 |
