Associated Spring Raymond - 42.85mm OD, 3.76mm Wire, 50.8mm Free Length, Compression Spring - 63.4 Lb Spring Rating, 220.49 N Max Work Load, Music Wire
Item #: 69080638
Brand: Associated Spring Raymond
Model #: C16871482000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 42.85 |
| Outside Diameter (Decimal Inch) | 1.6870 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 63.4000 |
| Maximum Work Load (N) | 220.49000549 |
| Solid Height (mm) | 20.62 |
| Solid Height (Decimal Inch) | 0.8120 |
| Material | Music Wire |
| Wire Size (mm) | 3.76 |
| Wire Size (Decimal Inch) | 0.1480 |
