Associated Spring Raymond - 42.85mm OD, 4.11mm Wire, 1-1/2" Free Length, Compression Spring - 125.8 Lb Spring Rating, 283.12 N Max Work Load, Music Wire
Item #: 69080521
Brand: Associated Spring Raymond
Model #: C16871621500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 42.85 |
| Outside Diameter (Decimal Inch) | 1.6870 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 125.8000 |
| Maximum Work Load (N) | 283.11999512 |
| Solid Height (mm) | 19.43 |
| Solid Height (Decimal Inch) | 0.7650 |
| Material | Music Wire |
| Wire Size (mm) | 4.11 |
| Wire Size (Decimal Inch) | 0.1620 |
