Associated Spring Raymond - 27.94mm OD, 2.44mm Wire, 2-1/2" Free Length, Compression Spring - 17.24 Lb Spring Rating, 82.96 N Max Work Load, Stainless Steel
Item #: 69078699
Brand: Associated Spring Raymond
Model #: C11000962500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 27.94 |
| Outside Diameter (Decimal Inch) | 1.1000 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 17.2400 |
| Maximum Work Load (N) | 82.95999908 |
| Solid Height (mm) | 20.32 |
| Solid Height (Decimal Inch) | 0.8000 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.44 |
| Wire Size (Decimal Inch) | 0.0960 |
