Associated Spring Raymond - 27.94mm OD, 2.67mm Wire, 1-1/2" Free Length, Compression Spring - 50.4 Lb Spring Rating, 127.79 N Max Work Load, Music Wire
Item #: 69078467
Brand: Associated Spring Raymond
Model #: C11001051500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 27.94 |
| Outside Diameter (Decimal Inch) | 1.1000 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 50.4000 |
| Maximum Work Load (N) | 127.79000092 |
| Solid Height (mm) | 16.05 |
| Solid Height (Decimal Inch) | 0.6320 |
| Material | Music Wire |
| Wire Size (mm) | 2.67 |
| Wire Size (Decimal Inch) | 0.1050 |
