Associated Spring Raymond - 31.12mm OD, 2.16mm Wire, 50.8mm Free Length, Compression Spring - 14.1 Lb Spring Rating, 64.05 N Max Work Load, Music Wire
Item #: 69077246
Brand: Associated Spring Raymond
Model #: C12250852000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 31.12 |
| Outside Diameter (Decimal Inch) | 1.2250 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 14.1000 |
| Maximum Work Load (N) | 64.05000305 |
| Solid Height (mm) | 13.16 |
| Solid Height (Decimal Inch) | 0.5180 |
| Material | Music Wire |
| Wire Size (mm) | 2.16 |
| Wire Size (Decimal Inch) | 0.0850 |
