Associated Spring Raymond - 31.12mm OD, 2.44mm Wire, 1-1/4" Free Length, Compression Spring - 32.07 Lb Spring Rating, 74.86 N Max Work Load, Stainless Steel
Item #: 69076974
Brand: Associated Spring Raymond
Model #: C12250961250S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 31.12 |
| Outside Diameter (Decimal Inch) | 1.2250 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 32.0700 |
| Maximum Work Load (N) | 74.86000061 |
| Solid Height (mm) | 11.48 |
| Solid Height (Decimal Inch) | 0.4520 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.44 |
| Wire Size (Decimal Inch) | 0.0960 |
