Associated Spring Raymond - 31.12mm OD, 4.88mm Wire, 3-1/2" Free Length, Compression Spring - 184.8 Lb Spring Rating, 605.51 N Max Work Load, Music Wire
Item #: 69074516
Brand: Associated Spring Raymond
Model #: C12251923500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 31.12 |
| Outside Diameter (Decimal Inch) | 1.2250 |
| Free Length (mm) | 88.90 |
| Free Length (Decimal Inch) | 3-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 184.8000 |
| Maximum Work Load (N) | 605.51000977 |
| Solid Height (mm) | 58.95 |
| Solid Height (Decimal Inch) | 2.3210 |
| Material | Music Wire |
| Wire Size (mm) | 4.88 |
| Wire Size (Decimal Inch) | 0.1920 |
